Spherical Parking Lock with Key Included
- Electrostatically painted steel, yellow RAL 1023
- Spherical head, 4 kg
- Fixed with 4 anchors Ø16×90 mm and 4 bolts Ø10×110 mm
- Key included
Complementary products
General features
| Material | Painted Steel |
|---|---|
| Weight | 4 kg |
| Dimensions L X W X H | Ø30 x 8 x 65 cm |
| Base Dimensions L X W X H | 16 x 16 x 0.5 cm |
| Post Dimensions L X W X H | 8 x 4 cm |
| Folded Dimensions L X W X H | 30 x 65 x 6 cm |
| Color | Yellow (RAL 1023) |
| Mounting System | Screws Ø10×110 mm (x4), Dowels Ø16 x 90 mm (x4) |
| Length | 30 cm |
| Width | 16 cm |
| Height | 68 cm |
Product description
Parking lock with a spherical head and key
It is the only model in the range with a rounded Ø30 cm top. It looks less like site equipment, so it suits the entrance of an office, the front of a showroom or a well-kept residential courtyard.
It locks with a key, and the key is included. The body is electrostatically painted steel in yellow RAL 1023 and weighs 4 kg.
A base fixed at 4 points
The base is a 16×16 cm plate fixed with 4 anchors Ø16×90 mm and 4 bolts Ø10×110 mm – one more fixing point than the ATZ M601A and ATZ M602A.
The lowest when folded
Laid flat it measures 30×65×6 cm. At 6 cm it is the thinnest folded lock in the range, so it is also the easiest to drive over in a low car.
Fitting
On concrete or asphalt, with a hammer drill and a spanner. The anchors and bolts are in the box.
? Frequently asked questions
How does the spherical lock differ from the others?
It is the only model in the range with a rounded Ø30 cm top. It looks less like site equipment, so it suits the entrance of an office, the front of a showroom or a well-kept residential courtyard.
Is the key included?
Yes, the lock closes with a key, and the key is included.
How is the base fixed?
Can I drive over it in a low car?
Laid flat it measures 30×65×6 cm. At 6 cm it is the thinnest folded lock in the range, so it is also the easiest to drive over in a low car.
What is it made of and how is it fitted?
Electrostatically painted steel in yellow RAL 1023, weighing 4 kg. It fits onto concrete or asphalt with a hammer drill and a spanner.
Ordering and delivery
Can I order as a private individual?
Yes. You order directly on the site, as an individual or a company, and pay by card or cash on delivery.
Do I get an invoice?
Yes. Every order comes with a tax invoice, issued to an individual or a company.
Can I buy through SEAP / SICAP?
Yes. Public institutions find us in SICAP as S.C. ATTO REGAL S.R.L. Our company details are on the Purchase through SEAP / SICAP page.
How long does delivery take?
We deliver by courier within 24-48 hours.
Can I return the product?
Yes. As a private individual you can return the product within 14 days of receiving it, as the law provides, and you get your money back within 14 days of telling us. Return shipping is paid by the customer. The full terms are on the Return policy page.
