L8 Panel – Pedestrian Crossing, 85x85 cm, Class II

L8 Panel – Pedestrian Crossing, 85x85 cm, Class II

The pedestrian crossing sign in its high-visibility version: an 85x85 cm blue square with a class II prismatic face and a 10 cm border in class 3 fluorescent yellow-green sheeting. It is used at crossings where drivers must see as early as possible that pedestrians may appear, for example near schools or on roads running through villages.

Class II with a class 3 fluorescent border

The panel combines two sheetings: the face is class II (RA2) prismatic sheeting, which returns roughly three to four times more light to the driver than class I sheeting, and the 10 cm border is fluorescent yellow-green class 3 sheeting, the colour SR 1848-1:2024 requires for special situations. Fluorescent sheeting stands out in daylight too, in dull weather or at dusk, not only in headlights. SR 1848-2 guarantees a 10-year service life for classes 2 and 3.

Where it goes, under SR 1848-1:2024

It goes under the same conditions as the G1 (Pedestrian crossing): immediately before the crossing, level with the transverse stop line marked before the crossing stripes. SR 1848-1:2024 provides it to improve road safety, because the fluorescent yellow-green retroreflective border gives better visibility both by day and at night.

SR 1848-1:2024 reserves panels with a fluorescent yellow-green retroreflective background, class 3, for places that are particularly dangerous. Such a panel can carry a single sign, a group of two signs or signs with additional panels.

Technical data

• 85x85 cm blue panel with a white triangle and a black pedestrian on the crossing, inside a 10 cm fluorescent yellow-green border;
• 1 mm galvanised steel sheet, with rounded corners and pressed edges, no sharp edges;
• electrostatically painted with UV-resistant paint;
• face in class II (RA2) prismatic retroreflective sheeting, resistant to UV and weathering;
• border in class 3 fluorescent yellow-green retroreflective sheeting;
• guaranteed sheeting service life: 10 years;
• fixings included: 2 clamps for Ø48 mm posts and 4 bolts with nuts;
• CE marked; compliant with SR EN 12899-1:2007, SR 1848-1:2024, SR 1848-2:2011 and SR 1848-3:2011.

Mounting and size

Fixings for the post are included: 2 clamps for Ø48 mm posts and 4 bolts with nuts; clamps for Ø60 mm posts are available on request. The bottom edge of the panel goes 1.50–2.50 m above the road or kerb, and the edge nearest the road 0.50–2.0 m from the road platform.

The post is ordered separately. For a fixed installation in a concrete foundation: the galvanised Ø48 mm post, 300 cm. For temporary use, with no foundation: the Ø48 mm tripod post, 120 cm. On concrete or paving, where you cannot dig: the Ø60 mm flange post, 300 cm, bolted down; for it, ask for the Ø60 mm clamps when you order.

The 85x85 cm size with a 10 cm border is the one SR 1848-2 sets for the bordered pedestrian crossing sign; the standard sign measures 65x65 cm (in class II: the G1_II). The version with a class I face is the L8.
