| Material | PPC, TPU |
|---|---|
| Size (Post) | Ø9 x 50 cm |
| Size (Base) | 100x20 cm |
| Color | Yellow, Orange |
| Reflective | 2 Cat's Eye, 2 Metallic |
| Installation | 4 Dowels, 4 Screws |
| Weight | 4 kg |
| Length | 100 cm |
| Width | 20 cm |
| Height | 8 cm |
A traffic separator physically divides two lanes or two directions of travel where the line on the asphalt is not enough: on the approach to a junction, along a turning lane, at the edge of a cycle lane. This one has a yellow PPC base, 100 x 20 cm and 8 cm high, holding an orange TPU post 50 cm tall.
The post carries 2 white metallised reflective bands and the base has 2 red cat's eyes. By day the yellow and orange do the work; at night the headlights pick up the reflectors.
TPU is an elastic material. If a wheel or a wing mirror clips the post, it bends and returns to its original position instead of snapping.
The base is fixed at 4 points with 4 anchors and 4 bolts, supplied in the box. Each piece weighs 4 kg and is 1 m long, so a continuous 10 m line takes 10 separators placed end to end.
Placement follows SR 1848-1:2024. The separator can serve as a temporary marking while roadworks or a traffic diversion last, or stay in place as a permanent solution.
The V18-1070 uses the same base with a 70 cm post and 3 reflective bands.
