A46 Two-Way Directional Marker, 37.5x100 cm, Class II
- Marker A46 “Two-way directional marker”, to SR 1848-1:2024.
- 37.5x100 cm rectangular board with red and white bars slanting both ways, in 1 mm galvanised steel sheet.
- Class II (RA2) prismatic sheeting, guaranteed 10-year service life.
- Fixings included: 3 clamps for Ø48 mm posts and 6 bolts with nuts.
- CE marked; sheeting and paint resistant to UV and weathering.
Complementary products
General features
| SR 1848-1 code | A46 |
|---|---|
| Name in the standard | Two-way directional marker |
| Type | Obstacle marker |
| Shape and colours | 37.5x100 cm rectangular board with red and white bars slanting both ways |
| Size | 37.5x100 cm |
| Material | Galvanised steel sheet, 1 mm |
| Construction | Rounded corners, pressed edges, no sharp edges |
| Painting | Electrostatic, UV-resistant paint |
| Retroreflective sheeting | Class II (RA2), prismatic, UV-resistant |
| Retroreflection (white, 0.2°/5°) | 250 cd/(lx·m²) |
| Sheeting service life | 10 years (SR 1848-2) |
| Fixings included | 3 clamps, 6 bolts with nuts |
| Post diameter | Ø48 mm (Ø60 mm on request) |
| Standards | SR EN 12899-1:2007, SR 1848-1:2024, SR 1848-2:2011, SR 1848-3:2011 |
| Marking | CE |
| Weight | 3,5 kg |
| Length | 38 cm |
| Height | 100 cm |
Product description
A46 Two-Way Directional Marker, 37.5x100 cm, Class II
The A46 two-way marker with class II prismatic sheeting goes on an obstacle that can be passed on either side, such as the nose of an island where the road splits. It is the same size as the class I version, with brighter sheeting.
Why class II
Class II means RA2 prismatic sheeting, which sends back three to four times more light than class I sheeting. It matters on fast roads and wherever the sign is seen at an angle, and in areas with street lighting, shop windows and advertising SR 1848-2 explicitly requires it, alongside class 3. The sheeting has a guaranteed 10-year service life.
Where it goes, under SR 1848-1:2024
It is used on roads where obstacles that must be passed around need to be marked. The slanted bars slope down towards both sides of the carriageway that can be used to pass. It is usually installed together with the D6 “Pass either side” sign.
Technical data
- 37.5x100 cm rectangular board with red and white bars slanting both ways;
- 1 mm galvanised steel sheet, with rounded corners and pressed edges, no sharp edges;
- electrostatically painted with UV-resistant paint;
- class II (RA2) prismatic retroreflective sheeting, resistant to UV and weathering, with a guaranteed 10-year service life;
- fixings included: 3 clamps for Ø48 mm posts and 6 bolts with nuts;
- CE marked; compliant with SR EN 12899-1:2007, SR 1848-1:2024, SR 1848-2:2011 and SR 1848-3:2011.
Mounting and size
Fixings for the post are included: 3 clamps for Ø48 mm posts and 6 bolts with nuts; clamps for Ø60 mm posts are available on request.
The post is ordered separately. For a fixed installation in a concrete foundation: the galvanised Ø48 mm post, 300 cm. For temporary use, with no foundation: the Ø48 mm tripod post, 120 cm. On concrete or paving, where you cannot dig: the Ø60 mm flange post, 300 cm, bolted down; for it, ask for the Ø60 mm clamps when you order.
The marker is the same size, 37.5x100 cm, as the class I sheeting version, the A46; only the sheeting class differs.
? Frequently asked questions
Where does it go?
It is used on roads where obstacles that must be passed around need to be marked. The slanted bars slope down towards both sides of the carriageway that can be used to pass. It is usually installed together with the D6 “Pass either side” sign.
How does it differ from the class I sheeting version?
It is the same size as the A46, but with class II (RA2) prismatic sheeting, which returns three to four times more light and has a guaranteed 10-year service life instead of 7.
When is class II sheeting mandatory?
SR 1848-2 requires prismatic class 2 or 3 sheeting in areas with many light sources: street lighting, shop windows, advertising, dense urban areas. Elsewhere, class II is chosen for better visibility on fast roads and where the sign is seen at an angle.
Which fixings come with it?
The pack holds 3 clamps for Ø48 mm posts and 6 bolts with nuts. Clamps for Ø60 mm posts are available on request, a better fit for large signs or windy locations.
Which post should I order?
The post is ordered separately. For a fixed installation in a concrete foundation: the galvanised Ø48 mm post, 300 cm. For temporary use, with no foundation: the Ø48 mm tripod post, 120 cm. On concrete or paving, where you cannot dig: the Ø60 mm flange post, 300 cm, bolted down, for which you ask for the Ø60 mm clamps when you order.
Is the marker CE marked?
Yes. It is CE marked and complies with SR EN 12899-1:2007, the European standard for vertical road signs, and with SR 1848-1:2024, SR 1848-2:2011 and SR 1848-3:2011. The sheeting and the paint resist UV and weathering.
Ordering and delivery
Can I order as a private individual?
Yes. You order directly on the site, as an individual or a company, and pay by card or cash on delivery.
Do I get an invoice?
Yes. Every order comes with a tax invoice, issued to an individual or a company.
Can I buy through SEAP / SICAP?
Yes. Public institutions find us in SICAP as S.C. ATTO REGAL S.R.L. Our company details are on the Purchase through SEAP / SICAP page.
How long does delivery take?
We deliver by courier within 24-48 hours.
Can I return the product?
Yes. As a private individual you can return the product within 14 days of receiving it, as the law provides, and you get your money back within 14 days of telling us. Return shipping is paid by the customer. The full terms are on the Return policy page.
