C35 Prohibition Sign – End of No Overtaking, Ø80 cm, Class II
- Prohibition sign C35 “End of no overtaking”, to SR 1848-1:2024.
- 80 cm diameter white disc with the two-car symbol in grey, in 1 mm galvanised steel sheet.
- Class II (RA2) prismatic sheeting, guaranteed 10-year service life.
- Fixings included: 2 clamps for Ø48 mm posts and 4 bolts with nuts.
- CE marked; sheeting and paint resistant to UV and weathering.
Complementary products
General features
| SR 1848-1 code | C35 |
|---|---|
| Name in the standard | End of no overtaking |
| Type | Prohibition or restriction road sign |
| Shape and colours | 80 cm diameter white disc with the two-car symbol in grey, crossed by a black diagonal band |
| Size | Ø80 cm |
| Format (SR 1848-2) | Large |
| Material | Galvanised steel sheet, 1 mm |
| Construction | Pressed edges, no sharp edges |
| Painting | Electrostatic, UV-resistant paint |
| Retroreflective sheeting | Class II (RA2), prismatic, UV-resistant |
| Retroreflection (white, 0.2°/5°) | 250 cd/(lx·m²) |
| Sheeting service life | 10 years (SR 1848-2) |
| Fixings included | 2 clamps, 4 bolts with nuts |
| Post diameter | Ø48 mm (Ø60 mm on request) |
| Standards | SR EN 12899-1:2007, SR 1848-1:2024, SR 1848-2:2011, SR 1848-3:2011 |
| Marking | CE |
| Weight | 5 kg |
| Height | 80 cm |
Product description
C35 Prohibition Sign – End of No Overtaking, Ø80 cm, Class II
The disc that ends a no-overtaking section, in the large Ø80 cm format with class II prismatic sheeting. It is installed as a pair with the sign at the start of the section and has the same size and sheeting, so drivers see just as clearly where the prohibition ends.
Why class II
The difference from class I shows at night: class II (RA2) prismatic sheeting returns three to four times more light, and the gap grows when the sign is mounted at the side, far from the centre of the road. On lit streets with shop windows and advertising, SR 1848-2 requires prismatic class 2 or 3 sheeting. The standard guarantees a 10-year service life for class II sheeting, three years more than for class I.
Where it goes, under SR 1848-1:2024
It goes where the no-overtaking section ends, the section having been signed at its start with the C25 (No overtaking of motor vehicles, except solo motorcycles and mopeds; in class II: the C25_II) or with the C26 (No overtaking for goods vehicles).
Technical data
- 80 cm diameter white disc with the two-car symbol in grey, crossed by a black diagonal band;
- 1 mm galvanised steel sheet, with pressed edges, no sharp edges;
- electrostatically painted with UV-resistant paint;
- class II (RA2) prismatic retroreflective sheeting, resistant to UV and weathering, with a guaranteed 10-year service life;
- fixings included: 2 clamps for Ø48 mm posts and 4 bolts with nuts;
- CE marked; compliant with SR EN 12899-1:2007, SR 1848-1:2024, SR 1848-2:2011 and SR 1848-3:2011.
Mounting and size
Fixings for the post are included: 2 clamps for Ø48 mm posts and 4 bolts with nuts; clamps for Ø60 mm posts are available on request. The bottom edge of the sign goes 1.50–2.50 m above the road or kerb, and the edge nearest the road 0.50–2.0 m from the road platform.
The post is ordered separately. For a fixed installation in a concrete foundation: the galvanised Ø48 mm post, 300 cm. For temporary use, with no foundation: the Ø48 mm tripod post, 120 cm. On concrete or paving, where you cannot dig: the Ø60 mm flange post, 300 cm, bolted down; for it, ask for the Ø60 mm clamps when you order.
The 80 cm diameter is the large format in SR 1848-2, required on national roads; motorways use the very large 100 cm format. County and local roads, streets and private roads open to public traffic only need the normal Ø60 cm format: the class I sheeting version is the C35.
? Frequently asked questions
Where does it go?
How does it differ from the class I sheeting version?
It is larger than the C35: Ø80 cm instead of Ø60 cm, and the class II (RA2) prismatic sheeting returns three to four times more light, with a guaranteed 10-year service life instead of 7.
Can I use the Ø60 cm version on a national road?
No. SR 1848-2 forbids using signs smaller than the format set for the road's category. National roads require the large Ø80 cm format, and motorways the very large Ø100 cm format.
When is class II sheeting mandatory?
SR 1848-2 requires prismatic class 2 or 3 sheeting in areas with many light sources: street lighting, shop windows, advertising, dense urban areas. Elsewhere, class II is chosen for better visibility on fast roads and where the sign is seen at an angle.
Which fixings come with it?
The pack holds 2 clamps for Ø48 mm posts and 4 bolts with nuts. Clamps for Ø60 mm posts are available on request, a better fit for large signs or windy locations.
How are the start and end of the prohibition signed?
The start of the section is marked with the C25_II and the end with the C35_II, both in the Ø80 cm format with class II sheeting, so the pair is equally visible at both ends.
Which post should I order?
The post is ordered separately. For a fixed installation in a concrete foundation: the galvanised Ø48 mm post, 300 cm. For temporary use, with no foundation: the Ø48 mm tripod post, 120 cm. On concrete or paving, where you cannot dig: the Ø60 mm flange post, 300 cm, bolted down, for which you ask for the Ø60 mm clamps when you order.
Is the sign CE marked?
Yes. It is CE marked and complies with SR EN 12899-1:2007, the European standard for vertical road signs, and with SR 1848-1:2024, SR 1848-2:2011 and SR 1848-3:2011. The sheeting and the paint resist UV and weathering.
Ordering and delivery
Can I order as a private individual?
Yes. You order directly on the site, as an individual or a company, and pay by card or cash on delivery.
Do I get an invoice?
Yes. Every order comes with a tax invoice, issued to an individual or a company.
Can I buy through SEAP / SICAP?
Yes. Public institutions find us in SICAP as S.C. ATTO REGAL S.R.L. Our company details are on the Purchase through SEAP / SICAP page.
How long does delivery take?
We deliver by courier within 24-48 hours.
Can I return the product?
Yes. As a private individual you can return the product within 14 days of receiving it, as the law provides, and you get your money back within 14 days of telling us. Return shipping is paid by the customer. The full terms are on the Return policy page.
